■ 규격표(H빔 -자형)
| 품번 |
상품명 |
바퀴외경
(D) |
바퀴폭
(W1-W2) |
로라턱 |
바퀴외경
(D1) |
볼트길이 |
볼트
(M) |
삽입베어링
(Z) |
허용하중
(kg) |
| HC-32049 |
HC-N3RHR |
75 |
39-32 |
7 |
60 |
30 |
18 |
6005 |
500 |
| HC-32050 |
HC-N4RHR |
98 |
49-40 |
9 |
83 |
38 |
20 |
6206 |
500 |
| HC-32051 |
HC-N5RHR |
128 |
54-42 |
12 |
107 |
38 |
20 |
6206 |
600 |
| HC-32052 |
HC-N6RHR |
148 |
60-45 |
15 |
128 |
38 |
20 |
6206 |
800 |
| HC-32053 |
HC-MC3RHR |
80 |
38-30 |
8 |
59 |
32 |
18 |
6004 |
400 |
| HC-32054 |
HC-MC4RHR |
100 |
43-36 |
7 |
81.5 |
38 |
20 |
6204 |
500 |
| HC-32055 |
HC-MC5RHR |
138 |
45-36 |
8.5 |
107 |
41 |
20 |
6304 |
1000 |
| HC-32056 |
HC-MC6RHR |
148 |
44-35 |
9 |
127 |
41 |
20 |
6304 |
1000 |
| HC-32057 |
HC-MC8RHR |
200 |
44-35 |
9 |
170 |
41 |
20 |
6304 |
1200 |
| H*B |
t1 |
t2 |
|
H*B |
t1 |
t2 |
| 100*75 |
3.2 |
4.5 |
|
200*100 |
3.2 |
4.5 |
| 100*100 |
3.2 |
4.5 |
|
200*100 |
3.2 |
6.0 |
| 100*100 |
6.0 |
9.0 |
|
200*150 |
3.2 |
4.5 |
| 125*75 |
3.2 |
4.5 |
|
|
|
|
| 125*100 |
3.2 |
4.5 |
|
|
|
|
| 125*125 |
6.0 |
9.0 |
|
|
|
|
| 150*75 |
3.2 |
4.5 |
|
|
|
|
| 150*75 |
5.0 |
7.0 |
|
|
|
|
| 150*100 |
3.2 |
4.5 |
|
|
|
|
|
|
